Material
filter media: glass fiber
Conduction layer: polypropylene
Shell end cover: polypropylene
Seals: silica gel, ethylene glycol, fluorinated rubber, etc.
Whatsapp:
+8613569807092E-mail:
sales@world-filters.comUsing ultra-fine glass fiber material, it is a kind of deep filter core with adsorption effect.
Effectively protect the terminal sterilizing filter core and prolong the life of the terminal filter core
Pressure difference is low and flow rate is large.
High amount of pollution, long service life
No fiber shedding
All liquid gases can be filtered
1.Pharmaceutical industry: pre-filtration of cell culture medium, serum and blood products; decarbonization filtration of raw drug solutions and preparations
2.Chemical industry: clarification and filtration of viscous liquids such as glue
3.gas filtration: compressed gas degranulation, deoiling filtration; gas pre-filtration for fermentation
|
Temperature tolerance |
≤80℃ |
|
Forward differential pressure |
≤4Bar（20℃）； ≤2Bar（80℃） |
|
Reverse differential pressure |
≤2Bar（20℃） |
|
Hot water sterilization |
85 °C for 40 minutes, up to 100 times |
|
Chlorination disinfection |
50 ppm, 25 °C, tolerance time up to 1000 hours |
|
GF |
Outer diameter |
Filtering precision |
Interface1 |
Interface 2 |
Seal |
length |
|
GF: Glass fiber |
A: 69 mm |
10: 1µm |
0: 222 |
0: Golden Eagle |
E: Ethylene propylene diene monomer |
05: 5 inches |
|
|
B: 65 mm |
30: 3µm |
1: 215 |
1: Flat concave |
F: All inclusive fluorine |
10 inches |
|
|
C: 83 mm |
50: 5µm |
3: 15 |
2: flat plug |
N: Nitrile |
20: 20 inches |
|
|
D: 130 mm |
1H: 10µm |
7: 226 |
3: Chinese New Year |
S: Silicone |
30: 30 inches |
|
|
E: 58 mm |
A1: 0.01µm |
F: Hiraguchi |
F: Hiraguchi |
V: Fluorine rubber |
40: 40 inches |
